Bending | 4 Rolls Bending Machine | |
| Release time:2016-08-05 15:33:25 | Browsing times： | |
 |
|
| TECHNICAL SPECIFICATIONS AND STANDARD ACCESSORIES • Very suitable for medium and heavy plates or stainless steel bending  • Ferrules in full circle or varying radiuses can be done easily• Pinch Roll and Lateral Rolls move pyramidal linear with hdraulic pistons • Overload Protection • Top Roll and Lateral Rolls are powered by hydromotor and planetary gearbox (3 roll driven system) • Three digital readouts for easy roll positioing • Hydraulic tiltable Drop-End for easy removal of finished ferrule • Easy operation with Mobile Control Panel • Welded Steel frames • Induction hardened forged SAE 1050 (CK 45) Steel Rolls • Conical Bending device • Central lubrication system • Hydraulic or electronic balancing system • Built according to EC Safety Directives and has CE • Double Speed Working System OPTIONAL EQUIPMENTS • Automation with NC and CNC Control • Overhead Crane for large diameters • Hydraulic Lateral Side Supports for large diameters • Hydraulic plate ejector • Ground and polished rolls • Infinitively variable speed system
Title： EZW12-30×3100mm 4 Rolls Bending Machine Usefull length：3100mm Maxnum plate thickness: 30mm Top rolls diameter：400mm Bottom rolls diameter: 300mm Motor power: 38.5 Kw Working speed: 1.5-5 m/min Dimension: 5850mm×2250mm×2350mm
|
|
|
|
